Appendix
Data formats
10

77 K-HB 13.0001-EN 2.1
10 Appendix
10.1 Data formats
Information area Data type
1 bit Bool
8 bits Byte, Char
16 bits Word, INT, DATE
32 bits DWord, DINT, REAL, TIME, TOD
10.2 GSE file
;==================================================================
;Configuration file for ”Fluxxtorque” as DP slave
;Lenze GmbH&Co.KG Kleinantriebe, D-32699 Extertal, Hans-Lenze-Straße 1
;Status Version 0.1 from 31 September 2004
;Format: GSE file revision 1.0
;Name: 931MW058F.GSE
;===================================================================
#Profibus_DP
GSE_Revision = 2
Vendor_Name=”Fluxxtorque”; vendor
Model_Name=”931_M/W”; model name
Revision=”VERSION 1.0”; model revision
Ident_Number = 0x058F; ident number
Protocol_Ident=0; PROFIBUS_DP Protocol
Station_Type=0; slave station
Slave_Family=1@Positionierantrieb@3000rpm
FMS_supp = 0; DP-/FMS-Mixed mode not supported
Hardware_Release=”V 1.1”; up to 32 characters
Software_Release=”V 1.3”; up to 32 characters
9.6_supp = 1; baudrate 9.6kB supported
19.2_supp = 1; baudrate 19.2kB supported
93.75_supp = 1; baudrate 93.75kB supported
187.5_supp = 1; baudrate 187.5kB supported
500_supp = 1; baudrate 500kB supported
1.5M_supp = 1; baudrate 1.5MB supported
