Parameter numbers
Data type - IO settings (PNU 102)
8

63 K-HB 13.0001-EN 2.1
8.7 Data type - IO settings (PNU 102)
PNU Subindex Description
Possible settings
Data type Lenze Selection
102 I/O - settings Array
1 Input:
(Object for drive with I/O input
functionality. Not for devices
with local CAN)
0 Unused
Bit [3 ... 0]
1 Reference
2 Output stage off
3 Quick stop
4 Goto 99
5 Synchronisation
6 Intermediate stop
7 Single step mode
Input:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 Unused
Bit [7 ... 4]
1 Reference
2 Output stage off
3 Reference window
4 Reference window
5 Goto 99
6 Synchronisation
7 Intermediate stop
8 Single step mode
Input is active:
(Object for drive with I/O input
functionality. Not for devices
with local CAN)
0 High
Bit [8]
1 Low
Input is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [9]
1 Low
”Left limit switch” is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [10]
1 Low
”Right limit switch” is active:
(Object for Fluxxtorque drive
with additional box. Not for
devices with I/O)
0 High
Bit [11]
1 Low
