8.1.9 Selector switch - status word bit 8 (PNU 938)
PNU Subindex Description
Possible settings
Data type Lenze Selection
938 0 Selector switch - status word
bit 8
Unsigned 16
1 0x804d
Selection Meaning Description
1 No following error / following error If the status word, bit 8, is assigned to this function, a HIGH
level indicates ”no following error” and a LOW level indicates
a following error.
0x8000 Brake engaged / disengaged Here, a HIGH level indicates an activated/engaged brake,
whereas a LOW level indicates a disengaged brake.
0x8001 Left limit switch is activated /
deactivated
This function serves to assign the limit switch status to the
status word bit. A HIGH level of the limit switch is indicated
through the bit value ”1”.
0x8002 Right limit switch is activated /
deactivated
0x8003 Activate / deactivate quick stop The quick stop status can be read out at this point. The bit
value ”1” indicates an active quick stop and bit value ”0”
indicates that no quick stop is active.
0x8004 Activate / deactivate reference switch The limit switch status can be read out using this function.
The bit value ”1” indicates an activated reference switch, bit
value ”0” indicates that the reference switch is not active.
0x8005 Activate / deactivate reference
window
0x8006 Driving record is active / inactive As soon as a driving record is processed by the motor, this
will be indicated by ”1”on the status word bit assigned to
this function.
0x8010 Inverter output is activated /
deactivated
Here, the status of the inverter output can be monitored. Bit
value ”1” indicates an activated output, bit value ”0”
indicates a deactivated output.
0x8020 Inverter output Output is activated /
deactivated
Here, the status of the inverter output can be activated. Bit
value ”1” indicates an activated output, bit value ”0”
indicates a deactivated output.
0x8030 Inverter input is activated /
deactivated
Here, the status of the inverter input can be monitored. Bit
value ”1” indicates an activated input, bit value ”0” indicates
a deactivated input.
0x8040 Inverter input 1-BCD is activated /
deactivated
This function serves to transmit the physical levels of the I/O
box inputs to the status word bit. The bit value ”0” indicates
a LOW level, bit value ”1” indicates a HIGH level.
0x8041 Inverter input 2-BCD is activated /
deactivated
0x8042 Inverter input 4-BCD is activated /
deactivated
0x8043 Inverter input 8-BCD is activated /
deactivated
0x8044 Inverter input 10-BCD is activated /
deactivated
0x8045 Inverter input 20-BCD is activated /
deactivated
0x8046 Inverter input 40-BCD is activated /
deactivated
0x8047 Inverter input 80-BCD is activated /
deactivated
0x8048 Inverter input Start is activated /
deactivated
