Parameter numbers
Explanation of the parameter numbers
Selector switch - control word bit 9 (PNU 932)
8
54
K-HB 13.0001-EN 2.1
8.1.6
Selector switch - control word bit 9 (PNU 932)
PNU
Subindex Description
Possible settings
Data type
Lenze
Selection
932
0
Selector switch - control word
bit 9
Unsigned 16
1
0x8020
Selection Meaning
Description
1 Jogging 2 ON / OFF
When the drive is ready to start and the control bit 8 is activated,
the jogging mode is started with the set jogging setpoints. When
the bit is reset, the jogging process is stopped again.
0x8000
...
0x8020
See PNU 931
8.1.7
Selector switch - control word bit 11 (PNU 933)
PNU
Subindex Description
Possible settings
Data type
Lenze
Selection
933
0
Selector switch - control word
bit 11
Unsigned 16
1
0x8020
Selection Meaning
Description
1 Start homing / cancel homing
This function serves to start or stop the homing mode via the
control word bit 11.
0x8000
...
0x8020
See PNU 931
8.1.8
Selector switch - control word bit 12 ... 15 (PNU 934 ... 937)
PNU
Subindex Description
Possible settings
Data type
Lenze
Selection
934
...
937
0
Selector switch - control word
Bit 12 ... 15
Unsigned 16
1
0x8020
Selection Meaning
Description
1 Reserved
0x8000
...
0x8020
See PNU 931
