41 User Manual
CAUTION : Jumping the incorrect ATX power supply pins can cause
permanent damage to the power supply.
!
Your Koolance system is designed to automatically filter air from the liquid. Before
filling, the cooling system should be “jump-started” to assist in the circulation pro-
cess.
Make sure the AC power cord is attached to the power supply. If the power supply has
a rear switch, it must be in the ON (-) position. Using the ATX Jumper Wire, insert the
metal prongs into pin numbers 4 and 6 on the 20-pin motherboard ATX power supply
connector (green and a black ground wire-- See diagram).
Testing & Filling
You should now hear the pumps running in an empty
reservoir.
The refill tap is located beneath the case. Turn the
system upside-down and remove the large slot-headed
screw.
With the system upside-down, insert the refill funnel.
4 6
