39 User Manual
Install the Second Hard Drive Kit as you
would a regular Cooler. Thermal encapsu-
late is applied to the drive, and the thin
metal “Containment Plate” is screwed over
it to the bottom of the hard drive.
If you have a Koolance chassis, the hard drive
cooler can be used with 2 hard drives. The
second hard drive will require a “Second Hard
Drive Kit” (purchased from your local
Koolance dealer).
The second drive is mounted upside-down
to the cooler, held in place via its own side-
mounting screws.
Rear view of Hard Drive Cooler Assembly for
first hard drive (above), and second hard drive (below)
First Hard Drive
Thermal Encapsulate
Liquid
Cooler
Mounting Screws
Second Hard Drive
Thermal Encapsulate
Containment Plate
Mounting Screws
