Koolance RM2-4U - Manual (Page 43)

38 Installing Coolers
Using the mixing utensil, apply the encapsu-
late to the largest heat-producing components:
the spindle motor and primary circuit chips
on the bottom side of the drive.
CAUTION : Some hard drives have open spindle motors or other
connections which encapsulate may interfere with. Tape should be
placed over these areas before applying the thermal encapsulate.
!
Use the included screws to mount the
cooler over the encapsulate on the bot-
tom side of the hard drive. The drive may
be mounted into your case via the cooler
or the drive.
