34 Installing Coolers
CAUTION : Installing the tension screw into the wrong cooler
receptacle can cause insufficient cooler contact, and may result in
hardware damage.
!
Many processor dies are not equidistant from one edge of the socket to the other.
For most AMD processors, the left or right receptacles will be used, depending on
which direction the CPU socket faces. For Pentium-4 processors, use the center
hole.
Intel P4
AMD
(right)
AMD
(left)
Socket alignment for
right AMD processors Socket alignment for
left AMD processors
Socket alignment for P-4
processors
