25 User Manual
Before securely clamping the coolers, you must cut appropriate lengths of tubing
with scissors to connect each device. If you are building a new computer system,
it may be easier to temporarily lay the motherboard and CPU inside the case to
better estimate the required amounts.
The Exos external (blue) tubing connects
to the first and last coolers in your
system. Standard (clear) tubing is used
in between each individual cooler.
Additional tubing has been included with
your system should you require it, and
more can be purchased from your
Koolance dealer.
With one of the connected
hoses, roughly estimate the
length you will need to your first
cooler (usually the CPU cooler),
and cut it.
Cut the second hose with enough
length to connect with the last
cooler that will be in your
system.
Using the standard clear tubing,
cut shorter pieces to link
between each individual cooler.
Cutting Tube Lengths
Reservoir Input
Heat Exchanger Output
Although it is most common for
tubing from the heat exchanger to
go directly to the CPU cooler, liquid
may circulate in either direction
through the coolers.
