The Syringe Model Selector contains the list of mountable syringe
models within the selected pump model (both standard and custom
syringe models). By default, the first syringe model in the list is selected.
When a syringe model is selected, its diameter is shown and the flow
range of the pump is automatically calculated (and displayed) based on
the speed range of the pump model and the syringe diameter.
The Flow Rate Edit box allows you to enter the desired flow rate
(positive values in the flow units selected). Flow rates can be changed
while the pump is running.
The flow rate value must always be within the flow range calculated.
If it is out of bounds it will be automatically changed to the maximum
or minimum of the range.
The flow rate units may be specified from a combination of volume
units (ml, µl, nl and pl) with time units (sec, min and hr).
Use the set of control buttons (“ Ж”, “Е” and “Stop”) to make the
pump to infuse / withdraw the selected flow rate and to stop the pump.
The flow rate edit box will be enabled only when a syringe model is
selected. Control buttons will be enabled whenever a valid flow rate
value is entered.
While a pump is being controlled manually, Adagio will be
responsible for sending the corresponding commands to the pump in
order to start and stop the infusion / withdrawal operations.
A
Command log area displays the list of commands sent to the
pump.
The
Close button enables you to close the Manual Pump Control
window while the pump is running. This allows you to open another
Manual Pump Control window and control other defined pumps. Pumps
that are running will be highlighted in green in the Pump Configuration
window.
The Stop and Close button stops any started operation and closes
the Manual Pump Control window.
