51
3 Operation and visualization
3.6 CompactFlash card
The CompactFlash card
1
menu can only be called up if the user who is logged
in has the right to do so. The rights are administered using the PC Security
Manager Software (PCS).
Automatic
storage of
measurement
data The data stored in the paperless recorder are automatically saved to the
CompactFlash memory card at regular intervals. The PC Evaluation Software
reads the data off the memory card and provides convenient functions for
evaluation.
The data stored on the external CompactFlash memory card and in the
recorder are not deleted when the configuration is altered.
v Additional information about the PC Evaluation Software (PCA3000) can be
found in the Operating Manual B 70.9701.0.
Loading and
saving the
configuration
data The configuration data can be downloaded from the CompactFlash memory
card and saved to the CompactFlash memory card. In addition, this makes it
possible to copy a configuration from one instrument to another (or to transmit
it from/to the setup software).
A configuration data file can be stored on the CompactFlash memory card.
Measurement data or other data already stored on the CompactFlash memory
card will not be overwritten during storing.
Start menu➔
CompactFlash
card The menu is called up via the start menu:
1. PC Card access made available by CSM FAT File System
Copyright © 1997-2002 CSM GmbH Filderstadt, Germany
h Select operating level CompactFlash card
h Enter selection with E
