2 Instrument description
12
H
The life of the background illumination can be prolonged through
the parameter “Display off” (screen saving).
A
The CompactFlash memory card must not be removed during
access (signal LED is on).
CompactFlash slot
for exchanging data (measurement data, configuration data,
user lists) between the recorder and the PC
Connection for the setup plug, for
configuring the instrument from the PC
Status line Channel line
Softkeys
Signal LED; lights up on accessing the CompactFlash memory card.
The card must not be removed while being accessed.
Ejector for the
CompactFlash memory card
