3 Operation and visualization
Current batch
report
Change between “current” and
last “completed” batch report
Change to the previous/
next visualization
Edit all editable parameters in the right column
Switch the four right-hand softkeys to additional functions
Switch the four right-hand softkeys to original functions
Show data of batch report as history in “vertical diagram”
.
Show data of batch report as history in
“horizontal diagram”
.
Show report data of batch
report
