3 Operation and visualization
38
Batch texts How can something be edited? Here is the summary again:
Texts can be edited on
the instrument and through
the setup software.
- configuration
- report/batches
- ext. report/batches
- batches
- line 1—10
- text in left column
- report / batches
- ext. report / batches
- edit
- batch report
Instrument:
Setup software:
If batch start/end/
duration are used,
the lines cannot be
edited.
Texts can be edited on
the instrument and by
using the setup software.
They can also be
transferred online to an
instrument, through the
setup software.
Instrument:
Instrument:
Setup software:
Setup software
(online):
- configuration
- report/batches
- ext. report/batches
- batches
- line 1—10
- default text
- visualization
- group 1—6
- current batch
report
-
- place red bar
- press
- edit
- report / batches
- ext. report / batches
- edit
- batch report
- make connection
- extras
- write interface
texts
1
2
3
again
The batch number can only
be edited on the instrument.
1. Only available, if the batch parameter “Text editable?” is set to “Yes”.
2. According to option, also or .
3. Each line has to be activated
for writing via interface. in the configuration
press
