37
3 Operation and visualization
Text field (4) Text field (4) is filled automatically by the recorder and cannot be altered.
Example: Parameter setting for line 8
Example: Parameter setting for line 9
Example: Parameter setting for line 10
Parameter for line 8 Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 8 ➔ Contents right column Batch start
Parameter for line 9 Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 9 ➔ Contents right column Batch end
Parameter for line 10 Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 10 ➔ Contents right column Batch duration
