3 Operation and visualization
36
Example: Parameter setting for line 6
The text in line 6 is selected from the internal text list of the recorder by linking
the internal logic inputs.
Text field (3) Text field (3) (line 7) can be written to as long as the batch is not completed.
The internal text editor (button
) can be used to input any number
of up to 16 digits. After the batch has been completed, the batch number is
automatically incremented.
Example: Parameter setting for line 7
Parameter for line 6 Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 6 ➔ Contents right column Binary-linked text
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 6 ➔ Binary linking Logic inp1-2
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 6 ➔ from text No. 80
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 6 ➔ Text editable? Yes
Configuration ➔ Texts ➔ Text 80 normal version
Configuration ➔ Texts ➔ Text 81 heavy version
Configuration ➔ Texts ➔ Text 82 plus version
Configuration ➔ Texts ➔ Text 83 plusC version
Parameter
Configuration … Binary-linked texts
Number of possible texts
Logic inp1-2 4
Logic inp1-3 8
Logic inp1-4 16
Logic inp1-5 32
Logic inp1-6 64
Parameter for line 7 Parameter setting
Configuration ➔ Report/Batches ➔
Ext.Report/Batches ➔ Batches ➔
Line 7 ➔ Contents right column Batch No.
