tinb01e1-f (2011-07) VGC401.om

63

Transmit:

ERR

[]

Receive:
Transmit:
Receive: xxxx


└─ x =

0000 –> No error

1000 –> Controller error

(See display on front panel)

0100 –> NO, HWR No hardware

0010 –> PAR, Inadmissible parameter

0001 –> SYN, Syntax error

The ERROR word is cancelled when read out. If
the error persists, it is immediately set again.


Transmit:

RES

[,x] []


└─ x = 1 –> Reset

Receive:
Transmit:
Receive: [x]x,[x]x,...


└─ List of all present error messages

xx =

0 –> No error

1 –> Watchdog has responded

2 –> Task fail error

5 –> EPROM error

6 –> RAM error

7 –> EEPROM error

9 –> DISPLAY error

10 –> A/D converter error

11 –> Sensor error (e.g. filament

rupture, no supply)

12 –> Sensor identification error



Error status

Reset
