background image

tinb01e1-f (2011-07) VGC401.om

61

Transmit:

COM

[,x] []


└─ Mode x = 0 –> 100 ms

1 –> 1 s (default)

2 –> 1 min.

Receive:

is immediately followed by the con-
tinuous output of the measured value in the
desired interval.

Receive:

x,sx.xxxxEsxx y

│ │

│ └───┴─ Measured value

1)

with pressure unit


└─ Status, x =

0 –> Measurement data okay

1 –> Underrange

2 –> Overrange

3 –> Sensor error

4 –> Sensor off (BAG, PEG)

5 –> No sensor

6 –> Identification error

7 –> Error BAG, BPG, HPG, BCG

1)

The 3

rd

and 4

th

decimal are always 0, except for

the CDG gauge.



Transmit:

HVC

[,x] []


└─ Mode x = 0 –> off (default)

1 –> on

Receive:
Transmit:
Receive: x

└─ Mode


Continuous output of
measured values
(RS232)

Activating/deactivating
the HV circuit and EMI
