INFICON Sensistor ISH2000 Hydrogen Leak Detector - Manual (Page 47)

Hydrogen leak detector Sensistor ISH2000 - Operating Manual
OM-Sensistor ISH2000-EN-201304 47
EN
Battery mode ON/OFF OFF
Brightness 0 - 21 21
Calibration Time Min Calibra. Time-30 s 8 s
Calibration Tolerance 0-100% 10%
Calibration Unit Several Choices cc/s
Calibration Value 1.00E-37 - 1.00E+37 1.00E+01
Contrast 0-20 10
Correlation Values 1.00E-37 - 1.00E+37 1.00E+00
Data Output No Data Output
Debug Mode ON/OFF OFF
Detector Signal Level 0 - 100% 20%
Direct sensitivity
adjustment ON/OFF ON
Display Threshold 0 - 100% 0%
Displayed Gas Several Choices 95%N2/5%H2
ILS500 Mode ON/OFF OFF
Interval 0 - 255 Days/Hours/Minutes
Invert Colors ON/OFF OFF
Language Several choices English
Leak Gas Several Choices H2N2
Measure/Print Button ON/OFF OFF
Measuring Unit Several Choices cc/s
Menu Mode Several Choices Combined Mode
Min Calibration Time 0 - 30 s 5 s
Min Presentation Time 120 s 1 s
Multipoint Measuring Several Choices OFF
Multipoint Measuring
Time 0.0 - 30.0 s 5.0 s
Number of significant
Digits 2/3 2
Password Max 12 characters “” = No password
Password protected
calibration ON/OFF OFF
Password Protection
Level Standard/High Standard
Probe Button Several Choices No Function
Probe Lamp ON/OFF OFF
Probe Type Several Choices Hand Probe
Purge Level 1.00E-37 - 1.00E+37 1.00E+02
Parameter Range Default
