Hydrogen leak detector Sensistor ISH2000 - Operating Manual
OM-Sensistor ISH2000-EN-201304 11
EN
3.2 Push-buttons
The functions of the push-buttons are shown at the lower edge of the display. In this
manual the buttons are numbered, from left to right, 1, 2, 3, and 4. The push-buttons
are used to:
•
Change from one menu item to another using the < and > buttons.
• Press Enter to move down to the nearest sub-menu.
• Press Save to save the set value.
• Press Undo to restore the previously set value.
• Press Esc to move up to the nearest higher level(s).
• Shortcut to reach functions as Volume Sensitivity (Sens), Calibration (Cal) and
Menu.
3.3 LEDs
The two LEDs indicate the status of the instrument as follows:
•
Green flashing slowly, during warming up phase.
• Green fixed light indicates that instrument is ready and hydrogen signal is below
Reject Level limit.
• Periodically flashing green or red calls for calibration.
• Alternating red and green light while the instrument establishes probe
communication.
• Red fixed light together with Reject on display means the instrument has detected a
leak larger than the set Reject Level limit.
• Red flashing rapidly, check message on screen. (See “Trouble-shooting” on
page 49.)
3.4 Ports and connections
The ports and connections are shown in Figure 3-2 on the next page.
NOTICE!
Always connect all four wires to the Power connector to
24VDC in order to operate.
