LD Protocol 27
438 1B6 Param PLC input configuration IO
module
R/W UINT8[10] Configuration of PLC input port of the IO module
Index 0...9 = PLC_IN1...PLC_IN10
See table
-6 = VALID_TRIGGER_N
-5 = START_STOP_N
-4 = CLEAR_N
-3 = STOP_N
-2 = START_N
-1 = CAL_EXTERN_N
0 = NO_FUNCTION
1 = CAL_EXTERN
2 = START
3 = STOP
4 = CLEAR
5 = START_STOP
6 = VALID_TRIGGER
Default:
PLC_IN 1: NO_FUNCTION
PLC_IN 2: NO_FUNCTION
PLC_IN 3: START_STOPPLC_IN 4: NO_FUNCTION
PLC_IN 5: CAL_EXTERN
PLC_IN 6: NO_FUNCTION
PLC_IN 7: CLEAR
PLC_IN 8: NO_FUNCTION
PLC_IN 9: NO_FUNCTION
PLC_IN 10: NO_FUNCTION
440 1B8 Meas Remaining life time COOL-
Check [d] UINT16 Days until internal reference leak is empty
450 1C2 Param Date+Time [YMDhms] R/W UINT8[6] Date and time
use only with array-index 255 (all bytes)
year (1..99), month, day,
hour (0..23), min, sec
459 1CB Param Phase R/W UINT8 Phase (Min: 0; Max:39)
460 1CC Param Calibration factor instrument R/W FLOAT Calibration factor (Min: 6, Default: 15, Max.: 80)
480 1E0 Param Auto standby interval [min] R/W UINT8 Auto standby interval 0 = OFF
485 1E5 Param User gas factors R/W FLOAT[3] Gas factors for user gases:
Index 0: User gas 1
Index 1: User gas 2
Index 2: User gas 3
486 1E6 Param Gas type (smart probe only) R/W UINT8 Gas type (smart probe only)
5 = R22
22 = R404A
23 = R407C
24 = R410A
25 = R134A
26 = HFO1234YR
27 = R32
40 = USER-GAS 1
41 = USER-GAS 2
42 = USER-GAS 3
489 1E9 Param ID of last calibrated probe R UINT16 ID of last calibrated probe (Min.: 0; Default: 2; Max.: 15)
490 1EA Param Probe ID R UINT16 ID of actual probe
Command
Class Name R/W Data type Description
dez hex
