LD Protocol

23

275

113

Status Cal history

CHAR[*]

Text of calibration in the history list.
To read send after the array index 255 the UINT8 history
list index (0...9).
Without history list index you will get the last (newest) entry.
Entry format:
Answer: Index, cal-factor, phase, leak rate, year/month/
day, hour:min:sec, INT/EXT/MAN, gas type, p1, p2, on
time, probeID, S-value, temperature, cal state
Example: 05 Fac:1.32E+01 Phase:35 Leak:3.59E+00
2013/02/07 15:23:25 EXT Smart R134a p1:+324 p2:-396
t_on:002 ProbeID:D535 S-value:550 T:+27.2 CalState:23

277

115

Status Last entry in error history

R

UINT8

Index of the last (newest) entry in the error history list

287

11F

Status Error history

R

CHAR[*]

Text of an error/warning in the history list.
To read send after the array index 255 the UINT8 history
list index (0...15).
Without history list index you will get the last (newest) entry.
Entry format:

289

121

Status Value of actual error

R

FLOAT

Value associated with the actual error or warning

290

122

Status Number of actual error

R

UINT16

Error number of the actual error or warning

294

126

Status Text of error number

R

CHAR[*]

text of an error/warning number
To read send after the index the UINT16 error number
Without error number you will get the actual error/warning
Use only with index=255!

295

127

Status Text of warning bits

R

CHAR[*]

Explanation text for a specific warning bit:
To read, send after the index the UINT8 bit position
Use only with index=255!

296

128

Status List of active errors

R

UINT16[10] Lists the error/warning numbers since the last "clear error"

Command

Class Name

R/W Data type Description

dez

hex
