24 LD Protocol
297 129 Status Present warnings R UINT32 Each bit represents a warning
Bit 0 = Warning main EEPROM
Bit 1 = Warning IR source
Bit 2 = not used
Bit 3 = not used
Bit 4 = WARNING_MAIN_TEMP
Bit 5 = WARNING_CAL_REQUEST
Bit 6 = WARNING_RTC
Bit 7 = WARNING_PROBE_COM
Bit 8 = WARNING_DIFF_PRESS
Bit 9 = WARNING_IO_DISCONNECT
Bit 10 = WARNING_PROBE_SUPPLY
Bit 11 = WARNING_I_MOD
Bit 12 = WARNING_PROBE_NO_ANSWER
Bit 13 = WARNING_PROBE_PARA
Bit 14 = WARNING_LEAK_EMPTY
Bit 15 = WARNING_LEAK_NEARLY_EMPTY
Bit 16 = WARNING_LEAK_EEPROM
Bit 17 = WARNING_LEAK_TEMP
Bit 18 = WARNING_LIGHT_BARRIER
Bit 19 = WARNING_AUDIO_AMPLIFIER
Bit 20 = WARNING_12V_OUT_OF_RANGE
Bit 21 = WARNING_12VN_OUT_OF_RANGE
Bit 22 = WARNING_5V_OUT_OF_RANGE
Bit 23 = WARNING_CU_DISCONNECT
Bit 24 = WARNING_3V3_OUT_OF_RANGE
Bit 25 = WARNING_24V_OUT_OF_RANGE
Bit 26 = WARNING_NO_ANSWER_BUS_MOD
Bit 27 = WARNING_LAMP_VOLTAGE
300 12C Status Device identification R UINT8[2] Device identification, always {1,50} for HLD6000
301 12D Status Device name R CHAR[*] Get device name as ASCII string, always "HLD6000"
302 12E Status Sniffer probe type R UINT8 0: probe not detected
1: HLD5000-probe
2: HLD6000-probe
310 136 Status SW-version main board R UINT8[3] Software version
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
311 137 Status SW-version probe
programming master
R UINT8[3] Software version of master, by which this sniffer probe was
programmed
Index 0: Main version
Index 1: Sub version
Index 2: always 0
312 138 Status SW-version sniffer probe R UINT8[3] Software version probe
Index 0: Main version
Index 1: Sub version
Index 2: always 0
Command
Class Name R/W Data type Description
dez hex
