INFICON HLD6000 Refrigerant Leak Detector Interface Description User Manual
Page 10
10
ASCII Protocol
*MEASure:ACTTRIGger1:G/a
Actual trigger1 in g/a
383
R
*MEASure:ACTTRIGger1:LB/yr
Actual trigger1 in lb/yr
R
*MEASure:ACTTRIGger1:MBAR*l/s Actual trigger1 in mbar*l/s
R
*MEASure:ACTTRIGger1:OZ/yr
Actual trigger1 in oz/yr
R
*MEASure:ACTTRIGger1:PA*m3/s
Actual trigger1 in Pa*m3/s
R
*MEASure:ACTTRIGger2
Actual trigger in selected unit
R
*MEASure:ACTTRIGger2:G/a
Actual trigger1 in g/a
383
R
*MEASure:ACTTRIGger2:LB/yr
Actual trigger1 in lb/yr
R
*MEASure:ACTTRIGger2:MBAR*l/s Actual trigger1 in mbar*l/s
R
*MEASure:ACTTRIGger2:OZ/yr
Actual trigger1 in oz/yr
R
*MEASure:ACTTRIGger2:PA*m3/s
Actual trigger1 in Pa*m3/s
R
*MEASure:ANALOGIN
Analog input voltage of I/O-module [V]
220
R
*MEASure:ANALOGOUT1
Output voltage analog output channel 1
221
R
*MEASure:ANALOGOUT2
Output voltage analog output channel 2
221
R
*MEASure:DIGITALIN
state of the PLC inputs as 16-bit binary number;
inactive=0, active=1
Byte 0, Bit 0: PLC In 1
Byte 0, Bit 1: PLC In 2
Byte 0, Bit 2: PLC In 3
Byte 0, Bit 3: PLC In 4
Byte 0, Bit 4: PLC In 5
Byte 0, Bit 5: PLC In 6
Byte 0, Bit 6: PLC In 7
Byte 0, Bit 7: PLC In 8
Byte 1, Bit 0: PLC In 9
Byte 1, Bit 1: PLC In 10
Byte 1, Bit 2: DIP_1
Byte 1, Bit 3: DIP_2:
Byte 1, Bit 4: DIP_3:
Byte 1, Bit 5: DIP_4
Byte 1, Bit 6: DIP_5
261
R
*MEASure:DIGITALOUT
state of the PLC outputs as 16-bit binary number;
inactive=0, active=1
262
R
*MEASure:IIRSOURCE
IR source current [A]
179
R
*MEASure:P1
Actual differential pressure p1
484
R
*MEASure:P1:NOMINAL
Nominal differential pressure p1
483
*MEASure:P2
Actual differential pressure p2
484
R
*MEASure:P2:NOMINAL
Nominal differential pressure p2
483
R
*MEASure:REC0
Outpot voltage recorder channel 1
221
R
*MEASure:REC1
Outpot voltage recorder channel 2
221
R
*MEASure:SVALUE
S-Value
487
R
*MEASure:TEMPeratur:Electronic
Electronic temperature [°C]
165
R
*MEASure:TEMPeratur:Leak
Temperature of internal test leak [°C]
400
R
*MEASure:U12N
-12 V supply [V]
211
R
*MEASure:U12P
+12 V supply [V]
210
R
*MEASure:U24IO
24 V supply IO [V]
213
R
*MEASure:U24M12
24 V supply M12 connector [V]
219
R
Command
Meaning
Relates
to LD
cmd. no.
Read /
Write
