LD Protocol 25
313 139 Status SW-version I/O module R/W UINT8[3] Software version IO module
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
write for internal use only
314 13A Status SW-version control unit R/W UINT8[3] Software version control unit
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
write for internal use only
318 13E Status SW version boot loader R UINT8[3] Software version of boot loader
319 13F Status SW version boot loader I/O
module
R/W UINT8[3] Software version of boot loader IO module
write for internal use only
320 140 Status CRC-code main board R UINT32 CRC-code main board
High word: Caclulated value
Low word: Nominal value
321 141 Status DIP switch main board R UINT8 DIP switch setting of Mainboard:
Bit7: S100, switch 4
Bit6: S100, switch 3
Bit5: S100, switch 2
Bit4: S100, switch 1
Bit3...0: not used,always 0
332 14C Status SW version boot loader sniffer
probe
R UINT8[3] Software version of boot loader sniffer probe.
341 155 Status Last entry in long term history
list
R Text of long term history list.
To read send after the array index 255 the UINT8 history
list index (0...9).
Without history list index you will get the last (newest) entry.
Entry format: see enumerations table
342 156 Status Long term history list R Index of the last (newest) entry in the long term history list
383 17F Param Actual setpoint [g/a] R FLOAT[2] Actual leackage rate setpoint in g/a
385 181 Param Setpoint [g/a] R/W FLOAT[2] Desired leakage rate setpoint in g/a;
for actual used setpoint see command 383
388 184 Param Test leak extern [g/a] R/W FLOAT External test leak in g/a (Min.: 0.2; Default: 5; Max: 99)
394 18A Meas COOL-Check leak rate [g/a] R FLOAT[3] Leak rate of internal reference leak in g/a
0: nominal lr at 20 deg.C
1: Temperatur compensated lr
2: T compensated lr for actual gas
400 190 Meas COOL-Check temperature
[deg. C] R FLOAT Temperatur of internal reference leak in degree celsius
404 194 Status Serial number sniffer probe R CHAR[11] Serial number sniffer probe (ASCII)
406 196 Status Serial number leak detector R CHAR[11] Serial number of the complete leak detector (ASCII)
407 197 Status Serial number IR sensor R CHAR[11] Serial number of IR sensor in sniffer probe (ASCII)
408 198 Status Serial number IO module R/W CHAR[11] Serial number of the IO module
Command
Class Name R/W Data type Description
dez hex
