INFICON LDS3000 Modular Leak Detector Interface description User Manual
Page 46
46
LD Protocol
Bus module fieldbus type (command 324)
Bus module state (command 330)
PLC input configuration IO module (command 438)
Value
Meaning
0x0005
Profibus
0x0020
CANOpen
0x0065
ControlNet
0x0084
Profinet IO
0x0096
Profinet IO 2-port
0x0085
Ethernet IP
0x0087
EtherCAT
0x0080
Modbus TCP
0x0090 CCLInk
0x0045
ModbusRTU
0x0025
DeviceNet
Value
Meaning
0
SETUP
1
NW_INIT
2
WAIT_PROCESS
3
IDLE
4
PROCESS_ACTIVE
5
ERROR
6
UNKNOWN
7
EXCEPTION
Value
Meaning
-16
CAL
-15
KEY_3_N
-14
KEY_2_N
-13
KEY_1_N
-12
START_STOP_N
-11
SELECT_DYN_NORMAL_N
-10
GASBALLAST_N
-9
CLEAR_N
-8
ZERO_PULS_N
-7
ZERO_N
-6
STOP_N
-5
START_N
-4
SNIFF_VAC_N
-3
CAL_INTERN_N
-2
CAL_EXTERN_N
-1
DYN_CAL_N
0
NO_FUNCTION
1
DYN_CAL
2
CAL_EXTERN
3
CAL_INTERN
4
SNIFF_VAC
5
START
