LD Protocol 35
262 106
PLC output
state IO modul
R UINT8
Get PLC output state IO modul
Bit0..7 = PLCOut 1..8
263 107
PLC output
configuration
IO modul
R/W SINT8[8]
PLC_OUT1: -16, -
2, 16
PLC_OUT2: -16, -
3, 16
PLC_OUT3: -16, -
4, 16
PLC_OUT4: -16, -
5, 16
PLC_OUT5: -16, -
6, 16
PLC_OUT6: -16, -
8, 16
PLC_OUT7: -16,
0, 16
PLC_OUT8: -16,
0, 16
Index 0...7 = PLC_OUT1 ... PLC_OUT_8
See table "PLC output conf."
264 108
Emission
actual status
R UINT8
Emission status:
STOP= 0
START= 1
WAIT= 2,
RAMP= 3,
REGULATE= 4
STABLE= 5
DOWN= 6
OFF= 7
274 112
Last entry in cal
history
UINT8
History list index of the last (newest)
entry in the calibration history
275 113 Cal history CHAR[*]
Text of calibration in the history list.
To read send after the array index 255
the UINT8 history list index (0...9).
Without history list index you will get the
last (newest) entry.
Entry format: see enumerations table
277 115
Last entry in
error history
UINT8
Index of the last (newest) entry in the
error history list
287 11F Error history R CHAR[*]
Text of an error/warning in the history
list.
To read send after the array index 255
the UINT8 history list index (0...15).
Without history list index you will get the
last (newest) entry.
Entry format: see enumerations table
288 120
TMP error
history
R CHAR[*]
Text of an error/warning in the TMP
history list.
To read send after the array index 255
the UINT8 history list index (1...10).
Entry format: see enumerations table
Comm
and dez
Com
mand
hex
Name R/W Data type
Min-, Def.-, Max-
value
Meaning
