INFICON LDS3000 Modular Leak Detector Interface description User Manual
Page 25
Binary Interface Protocol
25
56
57
GetTrigger
SetTrigger
Set / read trigger
Byte 0: 1...4 for Trigger
1...4
Byte 1: Einheit: 0-
mbar*l/s, 1-Pa*m³/s,
2-atmcc/s, 3-Torrl/s;
In sniff mode additional
4-ppm and 5-g/a
[float]: Trigger value
58
59
GetOpMode
SetOpMode
Set / read operation mode
0-Vacuum;
1-Sniff
60
61
GetStBy
SetStBy
Stand-By read / set
0-Stand-By;
1-measurement
62
GetErrorCode
Read actual error number
Actual error number
(1 Byte)
0= no error
63
SetClearError
Quit error / cancel calibration
66
67
GetTL
SetTL
Value of the calibrated leak
read / set
Byte 0: 0-int.TL;
1-ext.TL-vac;
2-ext.TL-sniff
Byte 1: unit: 0-mbar*l/s,
1-Pa*m³/s, .2-atmcc/s,
3-Torrl/s;
In sniff mode
additionally: 4-ppm,
5-g/a
5 [float]: value calibrated
leak
(Int.. cal : 1E-15mbarl/s for
no internal calibrated leak in
use)
68
69
GetFilterSetPoint
SetFilterSetPoint
Leak rate for switching the
averting time
Unit: 0-mbar*l/s, 1-
Pa*m³/s, .2-atmcc/s,
3-Torrl/s;
In sniff mode
additionally: 4-ppm,
5-g/a
[float]: LR-limit value
70
GetSerialNumber
Read serialnumber
72
GetState
State of the device
0-Standby; 1-error; 2-Cal;
3-run up; 4-ready;
5-Emisssion off
74
GetOpHours
Read operating hours
[uint; h];
76
GetSWVersionNr
Read software version
Byte 0: Main-Version;
Byte 1: Sub-Version
78
79
GetFacMachine
SetFacMachine
Read / set machine factor
[float]
Nr
Name
Description
Parameter
Data
