LD Protocol 33
145 91
TMP
temperature
bearing [deg.
C]
R FLOAT TMP temperatur bearing [deg. C]
146 92
TMP
temperature
motor [deg. C]
R FLOAT TMP temperatur motor [deg. C]
147 93
Time since
power on [min]
R UINT32 Time since power on [min]
148 94
Cathode1
operation hours
UINT32 Cathode1 operation hours
149 95
Cathode2
operation hours
UINT32 Cathode2 operation hours
150 96
TMP voltage
[V]
R FLOAT
TMP voltage as reported by TMP
controller
151 97 TMP current [A] R FLOAT
TMP current as reported by TMP
controller
157 9D
Switch on
counter
R UINT16
Counts the switch on cycles
0, 0, 65534
165 A5
Electronic
temperature
[deg. C]
R FLOAT MSB temperature in °C
166 A6
Preamplifier
temperature
[deg. C]
R FLOAT VV temperature in °C
167 A7
Anode voltage
[V]
R FLOAT Anode voltage in V
168 A8
Cathode
voltage [V]
R FLOAT Cathode voltage in V
169 A9
Suppressor
voltage [V]
R FLOAT Suppressor voltage in V
170 AA
Anode-cathode
voltage [V]
R FLOAT Anode/cathode voltage in V
171 AB
Emission
current [A]
R FLOAT Emission current (A)
172 AC Heater input [V] R FLOAT DAC heater (V)
200 C8 24 V supply [V] R FLOAT
24 V supply voltage for heater,
processor, preamplifier in V
202 CA
Pre amplifier
voltage [V]
R FLOAT Pre amplifier voltage [V]
206 CE
Heater voltage
[V]
R FLOAT Heater voltage in V
207 CF
Heater power
[W]
R FLOAT Heater power in W
209 D1
24 V power out
TMP [V]
R FLOAT 24 V TMP, MSB Pin C30 voltage in V
210 D2
+15 V supply
[V]
R FLOAT +15 V voltage in V
211 D3 -15 V supply [V] R FLOAT -15 V voltage in V
Comm
and dez
Com
mand
hex
Name R/W Data type
Min-, Def.-, Max-
value
Meaning
