LD Protocol 43
5.4 Enumerations
Analog output configuration (command 222)
Analog output leak rate scale (log. only) (command 223)
State calibration (command 260)
Value Meaning
0 off
1 p1
2 p2
3 Leak rate mantissa
4 Leak rate exponent
5 Leak rate linear
6 Leak rate logarithmic
7 Leak rate logarithmic H.
8 Voltage setable by command 221
9 Leak rate exponent invers
10 Leak rate mantissa hysteresis
11 p1 1V/decade
12 p2 1V/decade
Value Meaning
0 0,5 V / decade
1 1 V / decade
2 2 V / decade
3 2,5 V / decade
4 3 V / decade
5 5 V / decade
6 10 V / decade
7 special_1
Value Meaning
0 READY
1 START_INT
2 WAIT_TL_INT
3 PEAK_INT
4 MEAS_TL_INT
5 WAIT_ZERO_INT
6 MEAS_ZERO_INT
11 START_EXT
13 PEAK_EXT
14 MEAS_TL_EXT
15 WAIT_ZERO_EXT
16 MEAS_ZERO_EXT
21 START_DYN
25 WAIT_ZERO_DYN
26 ZERO_DYN
51 CURRENT
52 FAIL_STATUS
53 FAIL_TL_TO_SMALL
