36 LD Protocol
289 121
Value of actual
error
R FLOAT
Value associated with the actual error or
warning
290 122
Number of
actual error
R UINT16
Error number of the actual error or
warning
291 123
List of signal
values of active
errors
R
FLOAT[10
] Lists the signal values of the errors/
warnings since the last "clear error"
294 126
Text of error
number
R CHAR[*]
text of an error/warning number
To read send after the index the UINT16
error number
Without error number you will get the
actual error/warning
Use only with index=255!
296 128
List of active
errors
R
UINT16[1
0] Lists the error/warning numbers since
the last "clear error"
297 129
Present
warnings
R UINT32
Each bit represents a warning see
enumerations table
300 12C
Device
identification
R UINT8[2]
Device identification, always {1,45} for
MSB
301 12D Device name R CHAR[*]
Get device name as ASCII string, 'always
"MSB"
310 136
SW-version
MSB
R UINT8[3]
Software version MSB
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
313 139
SW-version I/O
modul
R/W UINT8[3]
Software version IO modul
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
314 13A
SW-version
control unit
R/W UINT8[3]
Software version control unit
Index 0: Main version
Index 1: Sub version
Index 2: Debug version
315 13B
SW version
TMP controller
R CHAR[6] Character string from turbo controller
316 13C
HW-version
TMP controller
R CHAR[6] Character string from turbo controller
317 13D
TMP controller
name
R CHAR[6] Character string from turbo controller
318 13E
SW version
boot loader
R UINT8[3] Software version of boot loader
319 13F
SW version
boot loader I/O
modul
R/W UINT8[3] Software version of boot loader IO modul
320 140
CRC-code
MSB
R UINT32
CRC-code interface board
abcdwxyz (hex)
abcd: caclulated value
wxyz: nominal value
Comm
and dez
Com
mand
hex
Name R/W Data type
Min-, Def.-, Max-
value
Meaning
