14 ASCII Protocol
:PLCOUTLINK
:1 or :1_2
:2 or :3_4
:3 or :5_6
:4 or :7_8
:5 or :9_10
:6 or :11_12
:7 or :13_14
:8 or :15_16
assignment of PLC-outputs
"OPEN", “INV_OPEN”,
"TRIGGER_1","INV_TRIGGER_1",
"TRIGGER_2","INV_TRIGGER_2",
"TRIGGER_3","INV_TRIGGER_3",
"TRIGGER_4","INV_TRIGGER_4",
"READY","INV_READY",
"WARNING","INV_WARNING",
"ERROR",”INV_ERROR”,
“CAL_ACTIVE",“INV_CAL_ACTIVE",
"CAL_REQUEST",”INV_CAL_REQUEST”,
"RUN_UP", “INV_RUN_UP”,
"ZERO_ACTIVE", "INV_ZERO_ACTIVE",
“EMISSION_ON", “INV_EMISSION_ON”
"MEASURE", “INV_MEASURE”,
"STANDBY", “INV_STANDBY”,
"SNIFF", “INV_SNIFF”
263 R/S
:PLCINLINK
:1
:2
:3
:4
:5
:6
:7
:8
:9
:10
assignment of PLC-inputs
(„NOT_USED“,
„DYN_CAL“, „INV_ DYN_CAL “,
„EXT_CAL“, „INV_ EXT_CAL “,
„INT_CAL“, „INV_ INT_CAL “,
„SNIFF“, „INV_ SNIFF“,
„START“, „INV_ START “,
„STOP“, „INV_ STOP “,
„ZERO“, „INV_ZERO“,
„ZERO_PULS”, „INV_ ZERO_PULS”
“CLEAR”, “INV_CLEAR”,
“GAS_BALLAST”, “INV_ GAS_BALLAST
”,"SEL_DYN_NORM", "INV_SEL_DYN_NORM",
"START_STOP", "INV_START_STOP",
„KEY1”, „INV_ KEY1”,
„KEY2”, „INV_ KEY2”,
„KEY3”, „INV_KEY3”,
)
438 R/S
:DECADEZero
zero function
„NORM“,(„1-2“, “2-3“, „19/20“, „2“, „3-4“)
410 R/S
*HOUR
:DATE date TT,MM,JJJJ 450 R/S
:DEVice operating hours of device 142 R
:POWer time since switching on (in minutes) 147 R
:TIME time hh,mm 450 R/S
:TURBO operating hours of TMP 140 R
:TC operating hours of converter 141 R
*FACtor
:FACSniff sniff factor 523 R/S
:FACMachine machine factor 522 R/S
:RESistor resistor factor 500 G / 15 G 504 R/S
Re
la
te
s to
L
D
cmd. no.
Read / Set
