ASCII Protocol 11
:TORR P2 pressure in Torr --- R
:P3 P3 pressure (only for service) 134 R
:P4 P4 pressure (only for service) 135 R
:UVV preamplifier voltage [V] 202 R
:MIAP anode potential [V] 167 R
:MIKP cathode potential [V] 168 R
:MISP suppressor potential [V] 169 R
:MIAKP anode-/cathode potential [V] 170 R
:U15N -15 V supply [V] 211 R
:U15P +15 V supply [V] 210 R
:U24 24 V supply [V] 200 R
:U24IO 24 V supply IO [V] 213 R
:U24IO_OUT 24V power out IO [V] 219 R
:U24PI 24 V power out pirani [V] 214 R
:U24PWR1_2 24 V power out12 [V] 215 R
:U24PWR5_6 24 V power out56 [V] 217 R
:U24RC 24V_2 power out RC [V] 212 R
:U5 +5 V supply [V] 218 R
:TEMPeratur
:Amplifier preamplifier temperature [°C] 166 R
:Electronic electronic temperature [°C] 165 R
:TCElectronic TMP electronic temperature [°C] 144
:TCPump TMP temperature bottom [°C] 143 R
:TCBearing TMP temperature bearing [°C] 145 R
:TCMotor TMP electronic temperature [°C] 146 R
:TURBO
:Frequency TMP frequency [Hz] 138 R
:Voltage TMP voltage [Hz] 150 R
:Current TMP current [A] 151 R
:Power TMP power [W] 139 R
:ANALOGOUT
1
Output voltage analog output channel 1 221 R
:ANALOGOUT
2
Output voltage analog output channel 2 221 R
Re
la
te
s to
L
D
cmd. no.
Read / Set
