Operating Instructions Safety System CES-AZ-UES-...
7
Independent of the switching state of the safety circuit, the position of all safety
doors can be polled via the outputs O1 or O1...O2 or O1...O4.
If an internal fault occurs in the evaluation unit, the safety circuit is switched off,
the diagnostic output (DIA) is set HIGH and the DIA LED illuminates red.
