Operating Instructions Safety System CES-AZ-UES-...
43
Actuator CES-A-BSP
Ì
Optimized for aluminum profile mounting
Dimension drawing CES-A-BSP
Technical Data
Parameter
Value
Unit
min.
typ.
max.
Housing material
Reinforced thermoplastic, fully encapsulated
Weight
0.02
kg
Ambient temperature
-25
-
+70
°C
Degree of protection
IP67
Installation position
Active face opposite read head
Power supply
Inductive via read head
97,
1
1
0
57,5
Ø 5,2
18,1
6
5
R2
Active face
