Technical Data CES-AZ-AES-04B
Parameter
Value
Unit
min. typ. max.
Housing material
Plastic PA6.6
Dimensions 114 x 99 x 45 mm
Weight 0.25 kg
Ambient temperature at U
B
= DC 24 V -20 - +55 °C
Atmospheric humidity, not condensing - - 80 %
Degree of protection IP20
Degree of contamination 2
Installation DIN rail 35 mm according to EN 60715
Number of read heads Max. 4 read heads per evaluation unit
Connection (plug-in screw terminals/coded) 0.14 - 2.5 mm²
Operating voltage U
B
(regulated, residual ripple < 5 %) 21 24 27 V DC
For the approval according to the following applies Operation only with UL Class 2 power supply, or equivalent measures
Current consumption I
B
(with relay energized) 1) - 150 - mA
External fuse (operating voltage U
B
) 0.4 - 8 A
Safety contacts 2 (relays with internally monitored contacts)
Switching current (relay outputs)
mA
- At switching voltage AC/DC 21 ... 60 V 1 - 300
- At switching voltage AC/DC 5 ... 30 V 10 - 6000
- At switching voltage AC 5 ... 230 V 10 - 2000
Switching load according to Max. AC 30 V, class 2 / max. DC 60 V, class 2
External fuse (safety circuit) according to EN 60269-1 6 A gG or 6 A circuit breaker (characteristic B or C)
Utilization category to EN 60947-5-1 AC-12 60V 0.3A / DC-12 60V 0.3A
AC-12 30V 6A / DC-12 30V 6A
AC-15 230V 2A / DC-13 24V 3A
Classification according to EN 60947-5-3 PDF-M
Rated insulation voltage U
i
250 V
Rated impulse withstand voltage U
imp
4 kV
Rated conditional short-circuit current 100 A
Resilience to vibration In acc. with EN 60947-5-2
Mechanical operating cycles (relays) 10 x 10 6
Switching delay from state change 2)
- 4 activated actuators - - 450
ms
- 3 activated actuators - - 370
- 2 activated actuators - - 290
- 1 activated actuator - - 210
Time difference between the switching points
of the two relays (with 4 activated actuators)
- - 25 ms
Manual start operating mode
- Duration of operation of start button
250 - -
ms
- Start button response delay - 200 300
Current via feedback loop Y1/Y2 5 8 10 mA
Permissible resistance via feedback loop - - 600 Ω
Ready delay 3) - 10 12 s
Dwell time 4) 3 - - s
Switching frequency max. 5) - - 0.25 Hz
Repeat accuracy R according to EN IEC 60947-5-3 ≤ 10 %
Monitoring outputs (diagnostics DIA, release 01...02, semi-
conductor output, p-switching, short circuit-protected)
- Output voltage
0.8 x U
B
- U
B
V DC
- Max. load - - 20 mA
Start button input S, test input TST
- Input voltage
LOW 0 - 2
V DC
HIGH 15 - U
B
- Input current HIGH 5 8 10 mA
EMC protection requirements In acc. with EN 60947-5-3
Reliability figures according to EN ISO 13849-1
as a function of the switching current at 24 V DC
≤ 0.1 A ≤ 1 A ≤ 3 A
Category 4
Performance Level (PL) e
PFH
d
1.9 x 10 -8
Mission time 20 years
Number of switching cycles/year 760 000 153 000 34 600
