Operating Instructions Safety System MGB-L..B-PNA-... (PROFINET)
25
Teach-in operation (only for MGB unicode)
The handle module must be assigned to the locking module using a teach-in func-
tion before the system forms a functional unit.
During a teach-in operation the system is in the safe state (bit SI10 is not set).
Important!
Ì The locking module disables the code for the previous handle module if
teach-in is carried out for a new handle module. Teach-in is not possible
again immediately for this device if a new teach-in operation is carried out.
The disabled code is deleted in the locking module only after a third code
has been taught.
Ì The locking module can only be operated with the last handle module taught.
Ì If, in the teach-in standby state, the locking module detects the handle
module taught-in or a disabled handle module, the teach-in standby state is
ended immediately and the locking module changes to the normal state or
indicates an error.
Ì If the bolt tongue is in the operating distance for less than 60 s, the handle
module is not taught.
Teaching in handle module
1. Fit handle module.
2. Close safety guard. Check for correct alignment and distance using the
marking on the locking module and re-adjust if necessary.
3. Insert bolt tongue in the locking module.
4. Apply operating voltage to the locking module.
Ì Teach-in process starts, green LED (DIA1) flashes slowly (approx. 2 Hz). The
teach-in standby state is active for 3 minutes after switch on. During teach-in,
the locking module checks whether the handle module is a disabled handle
module. Provided this is not the case, the teach-in operation is completed after
approx. 60 seconds, and the green LED (DIA1) goes out. The new code has
now been stored, and the old code is disabled.
5. Reset via bit O18 to activate the handle module's code from the teach-in
operation in the locking module.
