Operating Instructions Safety System MGB-L..B-PNA-... (PROFINET)
10
Case C
You have an MGB with a version number of V 2.36.4 and a GSD file with a version
number from ..._110026-20110815.
The guard locking solenoid is controlled if:
Ì bit SO1 = 1 (factory setting)
Truth table:
PROFINET bit PROFIsafe bit Guard locking with
O16
Not relevant
SO1 MGB-L1... MGB-L2...
0 0 active inactive
0 1 inactive active
1 0 active inactive
1 1 inactive active
What must be observed?
You can define in the GSD file whether bit O16 may be used for control in addition
to bit SO1. The setting is specified in the parameter Locking module – solenoid
control.
If O16 is additionally used, the guard locking solenoid is controlled if
for MGB-L1...
Ì bit SO1 AND bit 016 = 1
for MGB-L2...
Ì bit SO1 OR bit 016 = 1
Truth table:
PROFINET bit PROFIsafe bit Guard locking with
O16 SO1 MGB-L1... MGB-L2...
0 0 active inactive
0 1 active active
1 0 active active
1 1 inactive active
