ERICO Practical Guide to Electrical Grounding User Manual
Page 4
Table of Contents
Chapter
Description
Page
1
Building and Service Entrance Grounding -
1
The grounding of buildings and facilities where people work.
Building Grounding
Ground Resistance
Electrical Service Grounding
Ufer Grounding
2
Building Lightning Protection - A critical extension of grounding.
21
3
Building Interior Bonding and Grounding - The bonding and
47
grounding of building steel, electrical panels and other power
systems equipment.
Introduction
Bonding
Grounding
Ground Bars & Ground Bus
4
Transients & Other High Frequency Bonding and “Grounding” Requirements
65
The bonding and grounding of electronic systems.
5
Selection of Components Used in Grounding
79
Grounding Conductors
Connectors
Grounding Electrodes
6
Special Grounding Situations - Areas not covered elsewhere
89
Airports
Corrosion and Cathodic Protection
Radio Antenna Grounding
Static Grounding
Wire Mesh
Fences and Gates
7
Application of Surge Protection Devices
113
Definitions
119
References and Bibliography
121
Practical Guide to Electrical Grounding
ii
Grounding Book 4/14/99 10/5/99 6:01 PM Page ii (Black plate)
