SBG200 RAIL GRINDER PART LIST
Item ERICO ® Part No. Quantity Description
SBG200 Rail grinder assembly
1 SBG20001 2 Bearing housing
2 SBG20002 1 Drive shaft
3 SBG20003 1 Clutch guard
4 SBG20007 1 Throttle trigger
5 SBG20008 1 Base plate
6 SBG20009 1 Front plate
7 SBG20010 1 Handle assembly
8 SBG20014 1 Throttle cable
9 SBG20023 1 Engine
10 SBG20024 1 On/Off switch
11 A930U009 2 Bearing
12 A927D038 1 Screw, 3/8-16 x 1 in.
13 A927K029 4 Screw, M6 x 25 mm
14 A927P028 6 Screw, #8-32 x 5/8 in.
15 A927K097 2 Screw, M6 x 12 mm
16 A929A054 6 Flat washer, 6 mm
17 A927F179 2 Screw, 1/4-20 x 3/4 in.
18 A929E008 2 Belleville washer, 1/4 in.
19 SBG20026 2 Grip
20 SBG20029 1 Carrying case
21 B295X37 1 Precaution label
22 B295X38 1 Equipment safety label
23 B295X130 1 SBG200 label
24 B295X131 1 Recommended wheels label
25 B295X132 1 Service tag label
26 SBG200M 1 Instruction manual
27 SBG20015 1 Grinding wheel, Type 11 cup
28 G144A3 1 Wrench, 5/8-15/16
29 A927K098 1 Screw, #10-32 (LH) x 1/2 in.
30 A929B043 1 Lock washer, #10
31 A929A113 1 Fender Washer, #10
32 T391 1 Allen wrench, 5/32
33 SBG20015G 1 Grinding wheel guard (Type 11 & 18R)
34 SBG20018 3 Grinding wheel, Type 18R plug
35 A929B044 6 Lock washer, M6
36 A172A 2 Tie wrap
37 A929B045 1 Lock washer, M5
38 A927K099 1 Screw, M5 x 10 mm
39 SBG20028 1 Exhaust guard
40 A930A015 2 Rivet, 1/8 x 1/8 in.
41 B295X136 1 On/Off switch label
42 A927K061 1 Screw, M3 x 0.5 x 18 mm
Note: Items 20-26, 28, 32, and 41 are not shown in the assembly drawing.
