ERICO CSBSTU - Sway Brace Fitting, Standard Universal Sway Brace - Manual (Page 2)

1. UL Listed for use with Lightwall Service Pipe, Schedule 10, and Schedule 40 Service Pipe, for use with 1 to 2 NPS Schedule 40 brace pipe or 1/4" angle
iron (except for 10-inch).
*2. **2015 lbs. [8960 N] load rating when used with 1/4" angle iron.
**3. Rating with 1/4" angle iron is identical to Schedule 40 brace pipe.
UL® Loads (Listed for Restraints) - Lateral**
Part Number Dyna-Flow® Service Pipe Sch 10 Service Pipe Sch 40 Service Pipe
CSBSTU0100(XX) N/A 655 lb (2,914 N) 655 lb (2,914 N)
CSBSTU0125(XX) 655 lb (2,914 N) 655 lb (2,914 N) 655 lb (2,914 N)
CSBSTU0150(XX) 655 lb (2,914 N) 655 lb (2,914 N) 655 lb (2,914 N)
UL Loads (Listed for Sway Braces)
Part Number
Lateral* Longitudinal**
Dyna-Flow®
Service Pipe
EZ FLOW™
Service Pipe
Sch 10
Service Pipe
Sch 40
Service Pipe
Dyna-Flow®
Service Pipe
Mega-Flow
Service Pipe
Sch 10
Service Pipe
Sch 40
Service Pipe
CSBSTU0200(XX)
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A N/A N/A N/A
CSBSTU0250(XX)
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
2,015 lb
(8,963 N)
N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU0300(XX)
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
2,015 lb
(8,963 N)
N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU0400(XX)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
2,015 lb
(8,963 N)
N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU0500(XX) N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU0600(XX) N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU0800(XX) N/A N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A N/A
2,015 lb
(8,963 N)
2,015 lb
(8,963 N)
CSBSTU1000(XX) N/A N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
