Chapter 3: Installation
The Panther must be installed in a suitable environment and properly connected to its voltage
supplies and the motor.
3.1. Site Requirements
You can guarantee the safe operation of the Panther by ensuring that it is installed in an
appropriate environment.
Feature Value
Ambient operating temperature -40 °C to +70 °C (-40 °F to 160 °F)
Maximum operating altitude 12,000 m (39370 feet)
Maximum non-condensing humidity 95%
Operating area atmosphere No flammable gases or vapors permitted in area
Caution:
The Panther dissipates its heat by convection. The maximum operating ambient
temperature of 70 °C (160 °F) must not be exceeded.
3.2. Unpacking the Drive Components
Before you begin working with the Panther, verify that you have all of its components, as
follows:
• The Panther servo drive
• The Composer software and software manual
The Panther is shipped in a cardboard box with Styrofoam protection.
To unpack the Panther:
1.
Carefully remove the servo drive from the box and the Styrofoam.
2. Check the drive to ensure that there is no visible damage to the instrument. If any damage
has occurred, report it immediately to the carrier that delivered your drive.
