ABOUT THIS MANUAL

RFD

Oven Series Owner’s Manual

8

Version 1

Copyright © 2012 by Despatch Industries.

All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.

Danger!

Failure to heed warnings in this instruction manual and on the
oven could result in personal injury, property damage or death.

1.4. Conventions

This icon signifies information that describes an unsafe
condition that may result in death, serious injury, or damage
to the equipment.


Danger!

Danger is the signal word used to indicate a hazardous
situation that, if not avoided, will result in death or severe
injury.

Warning!

Warning is the signal word used to indicate a hazardous
situation that, if not avoided, could result in death or severe
injury.

Caution!

Caution is the signal word used to indicate a hazardous
situation that, if not avoided, could result in moderate or
minor injury.

Notice

Notice is the signal word used to indicate a hazardous
situation that, if not avoided, could result in property damage.


This icon signifies supplemental important information.

LOG OUT

Bold, 10 point sans-serif typeface indicates a specific key or
button on screen to click.

1.5. Specifications

1.5.1. Dimensions

Models

Chamber Size

inches (cm)

Capacity
ft

3

(liters)

Overall Size

inches (cm)

Maximum

Number of

Shelves (3

in. centers)

Exhaust

Outlet

Diameter

in (cm)

W

D

H

W

D

H

RFD2-13

24.5

(62)

25

(64)

37

(94)

13

(368)

67.5

(171)

42

(107)

91.5

(232)

12

7

(17.8)

RFD2-19

36.5

(93)

25

(64)

37

(94)

19.5

(552)

79.5

(203)

42

(107)

91.5

(232)

12

7

(17.8)

RFD2-35

47.5

(121)

30

(76)

42

(107)

35

(991)

92

(234)

47

(119)

96.5

(245)

14

7

(17.8)
