3.3. Optional Adjustable Louvers
This section applies only to ovens that include the optional
adjustable louvers. Ovens without the louver option do not have
adjustable airflow.
RFD oven series come standard with perforated supply and exhaust panels (Figure 7). Optional
adjustable louvers provide an extra measure of airflow customization (Figure 7). Figure 7 shows
the initial factory settings for the optional louvers.
Figure 7. Standard perforated panels and adjustable louvers.
Figure 8. Initial factory settings for optional louvers.
Standard perforated
panels
Optional adjustable
louvers
