8.2. MRC5000 Setup (Optional)


Refer to instructions provided recorder manufacturer for more
specific installation notes.

Temperature is retransmitted to the MRC5000 recorder from the controller. Set up the recorder
by:
1. Ensure hardware jumper JU1 is in place for the 5 VDC setting (Refer to MRC5000 Manual

included).

2. Move

MODE

to

PROG/TEST/CAL

to display

Prog

.

3. Press ▼ twice to display

Inps

. Move to each Parameter Code using ▼or ▲. Adjust each

Parameter Code using the settings in Table 6.

4. After adjusting all settings, move

MODE

to

RUN

. Display on both the recorder and controller

should read the same.

Table 6. MRC 5000 Settings.

Parameter Code

Degrees C

Degrees F

Inps

17

17

Icor

0

0

DiSP

On

On

Dpos

0

0

EUU

4

400

752

EUL

4

0

32

ChUP

400

800

5

ChLO

0

0

DFF

1

1



8.3. Electrical Schematics

The following pages contain electrical schematics for the RFD2-13, 2-19 and 2-35 ovens.


4

These values must match the settings RetOutLo and RetOutHi on the Protocol 3 Control page. For

example, if RetOutLo is 32, EUL must read 32.

5

Change 0-400 chart paper to 0-800 chart paper. Depending on the equipment, 0-600 paper may be used if

the maximum temperature is 260°C (500ºF).
