Parameter Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Profile Control 8245 0x2035 R/W 0 = Do Nothing
1 = Run the selected profile
2 = Hold the currently running profile
3 = Abort the currently running profile
4 = Jump to the next segment
5 = Release a held profile
6 = Exit the profile control once the profile has
completed and is holding the last setpoint
Active Profile
Name 8259 0x2043 R The currently selected profile name
Profile Status 8241 0x2031 R 0 = Stopped
1 = Running
2 = Held
3 = Delayed
4 = Error
5 = Aborted
6 = Ended
2.9. Uploading and Downloading of Profiles
The information in this section is intended for advanced users writing their own software code.
Most users will create or edit profiles using the instrument keypad or via BlueControl. Either
method allows quick and easy editing of profiles.
Advanced users can setup or edit profiles by writing to the Profile Configuration parameter at
address 8198 (0x2006). This can only be accessed by using Modbus function code 23 (0x17). The
instrument replies with a status message.
When creating a new profile the steps below must be followed exactly, either to create a profile at
the next available position, or at a position that you specify.
Each message in the sequence includes a 2 byte Command Code that tells the instrument the
purpose of the message, and therefore the meaning of the data contained in it.
The command codes support by this instrument are:
Command Code Value Decimal Value Hex Function
CP 17232 0x4350 Create Profile
EP 17744 0x4550 Edit Profile
WP 22352 0x5750 Write Profile
WS 22355 0x5753 Create Segment
IS 18771 0x4953 Insert Segment
ES 17747 0x4553 Edit a Segment
DP 17488 0x4450 Delete a Profile
DA 17473 0x4441 Delete all profiles
DS 17491 0x4453 Delete a Segment
SR 21330 0x5352 Get the number of segments remaining
RP 21072 0x5250 Read Profile Header
