Despatch Protocol 3 Modbus Communications - Manual (Page 25)

ADDRESS LIST Modbus Programming Manual
25 Version 2
Copyright © 2012 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means
including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without
the written permission of Despatch Industries, unless for purchaser's personal use.
Parameter Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Alarm inhibit
status 6165 0x1815 R 0 = Not inhibited
1 = Inhibited
Rate Minimum
Time Alarm
Value 6166
2.5.3. Alarm 3
Parameter Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Alarm Type 6176 0x1820 R/W 0 = High Alarm
1 = Low Alarm
2 = Deviation Alarm
3 = Band Alarm
4 = Loop Alarm
5 = Sensor Break Alarm
Alarm Value 6177 0x1821 R/W Limited by the input range maximum and minimum
for Alarm types 0 and 1. Limited by the span of the
input range for alarm types 2 and 3. Not used for
alarms 4 and 5.
Alarm Hysteresis 6178 0x1822 R/W Limited by the span of the input range
Alarm inhibit 6179 0x1823 R/W 0 = Disabled
1 = Enabled
Alarm status 6180 0x1824 R 0 = Inactive
1 = Active
Alarm inhibit
status 6181 0x1825 R 0 = Not inhibited
1 = Inhibited
Rate Minimum
Time Alarm
Value 6182 0x1826 R/W
2.5.4. Alarm 4
Parameter Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Alarm Type 6192 0x1830 R/W 0 = High Alarm
1 = Low Alarm
2 = Deviation Alarm
3 = Band Alarm
4 = Loop Alarm
5 = Sensor Break Alarm
Alarm Value 6193 0x1831 R/W Limited by the input range maximum and minimum
for Alarm types 0 and 1. Limited by the span of the
input range for alarm types 2 and 3. Not used for
