2.2.3. Relay Output 3 Parameters
Parameter
Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Usage 2186 0x088A R/W Value Usage
0 None
1 Alarm 1
2 Alarm 2
3 Alarm 3
4 Alarm 4
5 Alarm 5
6 Event 1
7 Event 2
8 Event 3
9 Event 4
10 Event 5
11 Cycle Complete
12 Profile Running
13 Or of Alarms
14 Alarm and Events
Alarm Selection 2188 0x088C R/W Value Selection
0 Alarm 1 or Alarm 2
1 Alarm 1 or Alarm 2 or Alarm 3
2 Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4
3 Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4 or Alarm 5
Event Alarm
Selection 2190 0x088E R/W Value Selection
0 Alarm 1 or Event 1
1 Alarm 2 or Event 2
2 Alarm 3 or Event 3
3 Alarm 4 or Event 4
4 Alarm 5 or Event 5
2.2.4. Relay Output 4 Parameters
Parameter
Name Modbus
Address
(Dec) Modbus
Address
(Hex) Access
R/W Notes
Usage 2205 0x89D R/W Value Usage
0 None
