Modbus Programming Manual
20
Version 2
Copyright © 2012 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means
including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without
the written permission of Despatch Industries, unless for purchaser's personal use.
Parameter
Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
11
Cycle Complete
12
Profile Running
13
Or of Alarms
14
Alarm and Events
Alarm Selection
2218
0x08AA
R/W
Value
Selection
0
Alarm 1 or Alarm 2
1
Alarm 1 or Alarm 2 or Alarm 3
2
Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4
3
Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4 or Alarm 5
Event Alarm
Selection
2220
0x08AC
R/W
Value
Selection
0
Alarm 1 or Event 1
1
Alarm 2 or Event 2
2
Alarm 3 or Event 3
3
Alarm 4 or Event 4
4
Alarm 5 or Event 5
2.2.6. Linear Output Parameters
Parameter
Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
Linear Output
Usage
2144
0x0860
R/W
Value
Usage
0
None
1
Retransmit PV
2
Retransmit SP
3
Primary (Heat) Control Power
4
Cool Control Power (Only available on
Heat Cool model)
Linear output
range
2223
0x08AF
R/W
Value
Range
0
0
– 5V
1
0
– 10V
2
2
– 10V
3
0
– 20mA
4
4
– 20mA
Retransmit
Minimum
2152
0x0868
R/W
Retransmit
Maximum
2153
0x0869
R/W
