ADDRESS LIST
Modbus Programming Manual
19
Version 2
Copyright © 2012 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any means
including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and retrieval systems without
the written permission of Despatch Industries, unless for purchaser's personal use.
Parameter
Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
1
Alarm 1
2
Alarm 2
3
Alarm 3
4
Alarm 4
5
Alarm 5
6
Event 1
7
Event 2
8
Event 3
9
Event 4
10
Event 5
11
Cycle Complete
12
Profile Running
13
Or of Alarms
14
Alarm and Events
Alarm Selection
2207
0x089F
R/W
Value
Selection
0
Alarm 1 or Alarm 2
1
Alarm 1 or Alarm 2 or Alarm 3
2
Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4
3
Alarm 1 or Alarm 2 or Alarm 3 or
Alarm 4 or Alarm 5
Event Alarm
Selection
2209
0x08A1
R/W
Value
Selection
0
Alarm 1 or Event 1
1
Alarm 2 or Event 2
2
Alarm 3 or Event 3
3
Alarm 4 or Event 4
4
Alarm 5 or Event 5
2.2.5. Relay Output 5 Parameters
Parameter
Name
Modbus
Address
(Dec)
Modbus
Address
(Hex)
Access
R/W
Notes
Usage
2216
0x08A8
R/W
Value
Usage
0
None
1
Alarm 1
2
Alarm 2
3
Alarm 3
4
Alarm 4
5
Alarm 5
6
Event 1
7
Event 2
8
Event 3
9
Event 4
10
Event 5
